Piusi Heavy Duty Hose Reel

1" (Max 15m)

Piusi Heavy Duty Hose Reel

Select image to zoom

From

£875.65

ex. VAT

Fluids

  • D
  • HVO/GTL
  • AdBlue
  • Air
  • Antifreeze
  • Any
  • Chemical
  • Diesel
  • Grease
  • Jet Fuel
  • Kerosene
  • Oil
  • Petrol
  • Rapsoil
  • HVO/GTL
  • Water
  • Windscreen
Piusi - The UK Agent

The Official UK agent of Piusi pumps & fuel dispensing equipment

About the product

The Piusi Heavy Duty Hose Reel has been designed specifically to ensure high efficiency when transferring a high volume of fuel or filling a high volume of vehicles. Popular with bunded fuel tank manufacturers for mounting directly onto the storage tank or for heavy-duty applications such as quarries, agriculture and construction, this retractable diesel fuel hose reel comes with a steel outlet, making it a more robust system.

One of the main differences compared to the Piusi Automatic Hose Reel is that the construction of the heavy duty hose reel has extra bends in the main column. This provides extra strength and stops the frame from twisting when the reel is in a fully extended position. This heavy-duty hose reel benefits from a protected latch mechanism to prevent injury to the hands when the reel is in use and has four-way rollers to guide the hose in any position that you decide to pull it. The diesel hose reel can be easily mounted in various positions without any problem with functionality and safety due to its adjustable arm brackets that allow easy positioning.

The Piusi Heavy Duty Hose Reel can be supplied complete with a range of hose lengths or a bare reel should the user wish to add their own choice of hose. The bare version of the Piusi retractable diesel fuel hose reel comes with a protection spring, hose stop and hose clamp for the easy connection of the user's choice of hose.

Features of the Piusi Heavy Duty Hose Reel:

  • Automatic spring rewind fuel hose reel
  • Sturdy heavy-duty steel structure
  • Reduced pressure loss through hydraulic sizing
  • Protected latch mechanism which prevents injury
  • Adjustable arm brackets for easy positioning
  • Can be supplied with or without a hose
  • 1" versions available
Read why you should accept nothing less than the market leading, Italian manufacturer of fluid handling equipment.

Read why you should accept nothing less than the market leading, Italian manufacturer of fluid handling equipment.

Product Models and Features

CodeModelDescriptionPrice
F0075025A1” Empty Hose Reel 15m XL Steel hub

Max Length (m) - 15

Max Pressure (Bar) - 10

Inlet - 1" F BSPP Swivel

Oulet - 1" Hose Barb

Pressure Loss (Bar) - 0.5@80 lpm

£875.65 ex. VAT
F0075026B1” Hose Reel c/w 15m XL Steel Hub

Max Length (m) - 15

Max Pressure (Bar) - 10

Inlet - 1" F BSPP Swivel

Oulet - 1" M BSP

Pressure Loss (Bar) - 0.8@80 lpm

£1,166.20 ex. VAT

If you are buying for resale and have volume enquiries, contact our sales team for pricing by clicking on the below product enquiry button or calling us on +44 (0) 121 351 4445.

Alternatively, visit our trade customers page where you can download account forms to apply for a credit account and receive exclusive trade benefits if approved including trade pricing.
