Piusi 3:1 Air Operated Oil Pump
21.5ltrs Per Min (3:1 ratio)
From
£343.70
ex. VAT
Fluids
- Oil
The Official UK agent of Piusi pumps & fuel dispensing equipment
About the product
New from Piusi is the “Pro + Silent” air operated oil pump range; part of their growing offering to the oil and lubrication market. The design of these air oil pumps has been specially considered to ensure high performance and durability in garage and workshop environments. These 3:1 air powered oil transfer pumps are designed for pumping medium viscosity oils over short to medium distances. They are available in stub and long length versions for mounting to a wall or drum respectively, and a range of optional accessories are available to go alongside the Piusi pump range (see accessories table).
For a more indepth guide to the design benefits that make the Piusi air operated pump range superior to alternatives, read here.
Please refer to our viscosity chart to check whether this oil dispensing pump is suitable for use with your oil.
Features of the Piusi 3:1 Air Operated Oil Pump:
- 3:1 ratio air operated oil transfer pumps
- Low operating noise of 77dB
- Pneumatic exchanger & three-stage air discharge system
- Enhanced efficiency & reduced air consumption
- Polyurethane internal seals
- Flow rate: 21.5ltrs per min
- Supplied with 2” BSP bung adaptor
- Available in stub (175mm) & long length (940mm)
- 175mm Stub Pump has 1” F BSP inlet thread
Read why you should accept nothing less than the market leading, Italian manufacturer of fluid handling equipment.
Product Models and Features
| Code | Model | Description | Price | |
|---|---|---|---|---|
| F0021400A | Piusi 3:1 Air Oil Pump 175mm (Stub) | Max Flow (lpm) – 21.5 Viscosity up to 550cSt Ratio – 3.5:1 Suction Pipe – 175mm Air Pressure (bar) – 3-8 Air Consumption (lpm) – 200-250 Air Inlet – ¼” F BSP Outlet – ½” M BSP 1” F BSP inlet thread | £343.70 ex. VAT | |
| F0021402A | Piusi 3:1 Air Oil Pump 940mm (Long) | Max Flow (lpm) – 21.5 Viscosity up to 550cSt Ratio – 3.5:1 Suction Pipe – 940mm Air Pressure (bar) – 3-8 Air Consumption (lpm) – 200-250 Air Inlet – ¼” F BSP Outlet – ½” M BSP | £390.45 ex. VAT |
Product Accessories
| Code | Accessory | Price | |
|---|---|---|---|
| F19979000 | Drip Tray | £74.80 ex. VAT | |
| F19975000 | Suction Pipe 385mm | £36.75 ex. VAT | |
| F19976000 | Suction Pipe 555mm | £38.05 ex. VAT | |
| F19977000 | Suction Pipe 765mm | £39.55 ex. VAT | |
| F19978000 | Suction Pipe 955mm | £40.40 ex. VAT | |
| F19972000 | Kit Suction Pipe | £195.95 ex. VAT | |
| F19973000 | ½” Piusi Oil Delivery Hose 2m Hose Length – 2m Inlet – ½” F BSP Outlet – ½” F BSP Max Pressure (bar) – 150 For Oil | £43.60 ex. VAT | |
| F19974000 | ½” Piusi Oil Delivery Hose 5m Hose Length – 5m Inlet – ½” M BSP Outlet – ½” F BSP Max Pressure (bar) – 150 For Oil | £90.15 ex. VAT | |
| F19965000 | Drum Trolley 30-60kg Wheels – 4 For Drum Size – 30-60kg For Any Fluid | £215.55 ex. VAT | |
| F19966000 | Drum Trolley 180-200kg Wheels – 4 For Drum Size – 180-200kg For Any Fluid | £432.95 ex. VAT |
Scroll left and right to view table
Is this oil transfer pump suitable for use with my oil?
Please refer to our oil viscosity chart detailing which of our pumps are compatible with a range of different grade oils and specific temperatures.
Resale and volume discounts are available. Send us a trade enquiry to receive your quotation today.
Apply for a credit account today to receive our exclusive benefit for trade customers only.
